1/2.8'' COMS Electronic Rearview Camera Lens IP69K CMS Lenses YT-7624-C1

YT-7624-C1: The Pinnacle of Clarity for Automotive Electronic Rearview Mirrors

Revolutionizing Rearview Technology

The YT-7624-C1 electronic rearview mirror lens is a testament to innovation in automotive vision systems. With an optical focal length (EFL) of 3.34mm and a total length (TTL) of 21.35mm, including a Back Focal Length (BFL) of 4.49mm, this lens sets the standard for electronic rearview mirror solutions.

High-Definition Imaging with a Wider Perspective

Designed to match a 1/2.8'' CMOS sensor with a resolution of 1920*1080, the YT-7624-C1 CMS Lens delivers 3 million clear pixels for high-definition imaging. The electronic rearview lens boasts a 112-degree diagonal field of view (Dfov), a 97-degree horizontal field of view (Hfov), and a 54° vertical angle, along with a maximum imaging circle diameter of 7.4mm, ensuring comprehensive coverage and clarity.

F/NO1.6 Aperture for Enhanced Night Visibility

Equipped with an F/NO1.6 large aperture, the YT-7624-C1 electronic rearview lens is built to perform in low-light conditions, ensuring enhanced visibility and safety during nighttime driving. The lens captures more light, providing bright and clear images that allow drivers to navigate with confidence.

Customizable Mounting for Seamless Integration

Featuring an M12 mount, the YT-7624-C1 CMS lens offers a standardized and secure connection to various automotive camera systems. The front cover diameter is 14mm, and the lens can be customized to an AA Gluing lens according to specific customer project requirements, ensuring adaptability for different applications.

Durable Construction with Advanced Optical Technology

The YT-7624-C1 electronic camera lens is encased in a robust metal barrel, showcasing its high-quality build. It utilizes a full-glass lens structure and includes a 650nm IR filter, ensuring excellent MTF performance and reliability. This advanced lens technology provides clear and vibrant images in all driving conditions.

Rugged and Reliable for Extreme Conditions

With an IP69K rating for dust and water resistance and TS16949 certification, the YT-7624-C1 electronic camera lens is built to withstand the harshest environments. It operates reliably in temperatures ranging from -40℃ to +85℃, making it a dependable choice for all weather conditions.

Versatile Applications for Extended Utility

The YT-7624-C1 lens's utility extends beyond electronic rearview mirrors. It is suitable for a multitude of applications, including streaming rearview mirrors, in-cabin passenger monitoring, electronic rearview mirrors, streaming media, action cameras, handheld gimbals, drones, intelligent robot cameras, AI cameras, consumer electronics, USB high-definition cameras, AI robot surveillance cameras, video conferencing cameras, smart home monitoring, USB surveillance, IP cameras, and facial recognition cameras.

In Summary

The YT-7624-C1 rearview lens is the epitome of automotive electronic rearview mirror technology, offering a combination of high-definition imaging, a wide field of view, and superior night vision capabilities. Its durable construction and advanced features make it an indispensable tool for vehicle safety and a wide range of imaging applications. Experience the versatility and excellence of the YT-7624-C1, ensuring that every journey is safer and more informed with clear rearview streaming.
